The Riser Door Specs and Options
The Riser is the Washers Solutions vinyl roll-up door built for car wash bays and tunnels For the full product overview, start with The Riser vinyl roll-up door. If you already know your opening size and want pricing or availability, request a Riser door quote.
Standard Sizes and Lead Times
The Riser is stocked in two standard sizes designed around common car wash bay applications:
Specification
Specification
Current Riser Detail
Standard stocked size
Current Riser Detail
10′ x 10′
Standard stocked size
Current Riser Detail
12′ x 10′
Custom sizes
Current Riser Detail
Special order
Stock door lead time
Current Riser Detail
Can go out the same week
Custom size or custom color lead time
Current Riser Detail
Expected 12-week lead time
Standard doors are the fastest path when an operator needs to replace a worn door, add a door to a bay, or reduce downtime during a door upgrade. Custom sizes are available, but they should be planned earlier because they are special order.
Stock and Custom Door Colors
Current stock car wash door colors are black, blue, red, and gray. Custom colors are available by special order. Transparent or full-vision sections are also available as an option and may affect final pricing and lead time. Confirm exact color, visibility, and curtain preferences before ordering.
Construction and Curtain Details
The Riser uses 304 stainless steel construction for rails, covers, and hardware areas described in the current product context. Washers Solutions pre-drills the 304 stainless rails to 3/4-inch holes to support faster installation. Hidden tubes in the rail help conceal wiring for a cleaner install.
304 stainless steel construction
0.8 basic vinyl thickness
Alloy wind bars
Extra bar available for heavier wind rating
Hidden tubes in the rail to hide wiring
The standard Riser door should not be described as a self-resetting breakaway door. If a vehicle impacts the door, components may need to be lifted back into the track, inspected, repaired, or replaced. For replacement components, see Riser door parts and replacement components.
The Riser Vinyl Roll-Up Door
The Riser uses a 220V single-phase motor. Current product context also references a motor life of 10 to 12 years and 500,000 to 1 million cycles, along with the ability to cycle up and down 120 times per hour.
A 220V car wash door motor should be reviewed as part of the site’s electrical planning before installation. Final electrical requirements, amp draw, disconnect needs, and local code requirements should be confirmed by the installer or licensed electrical partner for the project.
Controller and Adjustment Features
A key Riser advantage is the wall or ground-level car wash door controller. Instead of requiring adjustments at the motor overhead, the operator can manage settings from the controller interface.
Controller-based settings include speed, height settings, sensor settings, cycle count visibility, door parameter settings, and anti-freeze mode timing. This controller-first setup helps operators and installers adjust the door more practically after installation. For setup help, programming resources, and installation support, visit door installation and Riser resources.
Wi-Fi and Remote Access
The Riser supports Wi-Fi and remote access functionality. The Wi-Fi car wash door controller support can include remote control access and phone-based opening, depending on the final controller setup. Exact app, camera, network, and installation requirements should be confirmed during quoting.
Anti-Freeze Mode and Heated Rail Option
Cold-weather reliability matters for car wash operators. The Riser includes controller-set anti-freeze mode. When freezing conditions are expected, the operator can turn on anti-freeze mode so the door moves slightly up and down at a set interval to help reduce the chance of freezing to the ground.
Heated rails should be treated as an available or launch-ready option for The Riser, with final live copy matched to current inventory timing. The heated rail car wash door option is expected to include thermostat control through the controller. Confirm availability, lead time, and compatibility before ordering.
The anti freeze car wash door function is managed through the wall or ground controller, allowing operators to set timing and frequency without making overhead motor adjustments.
The Riser Vinyl Roll-Up Door
The Riser uses a 220V single-phase motor. Current product context also references a motor life of 10 to 12 years and 500,000 to 1 million cycles, along with the ability to cycle up and down 120 times per hour.
A 220V car wash door motor should be reviewed as part of the site’s electrical planning before installation. Final electrical requirements, amp draw, disconnect needs, and local code requirements should be confirmed by the installer or licensed electrical partner for the project.
Controller and Adjustment Features
A key Riser advantage is the wall or ground-level car wash door controller. Instead of requiring adjustments at the motor overhead, the operator can manage settings from the controller interface.
Controller-based settings include speed, height settings, sensor settings, cycle count visibility, door parameter settings, and anti-freeze mode timing. This controller-first setup helps operators and installers adjust the door more practically after installation. For setup help, programming resources, and installation support, visit door installation and Riser resources.
Wi-Fi and Remote Access
The Riser supports Wi-Fi and remote access functionality. The Wi-Fi car wash door controller support can include remote control access and phone-based opening, depending on the final controller setup. Exact app, camera, network, and installation requirements should be confirmed during quoting.
Anti-Freeze Mode and Heated Rail Option
Cold-weather reliability matters for car wash operators. The Riser includes controller-set anti-freeze mode. When freezing conditions are expected, the operator can turn on anti-freeze mode so the door moves slightly up and down at a set interval to help reduce the chance of freezing to the ground.
Heated rails should be treated as an available or launch-ready option for The Riser, with final live copy matched to current inventory timing. The heated rail car wash door option is expected to include thermostat control through the controller. Confirm availability, lead time, and compatibility before ordering.
The anti freeze car wash door function is managed through the wall or ground controller, allowing operators to set timing and frequency without making overhead motor adjustments.
Warranty and Support
The Riser currently includes a one-year warranty with exclusions. Earlier product documentation specifically referenced a one-year warranty on the motor and controller, while current client context describes a one-year warranty with normal exclusions.
Car wash door warranty terms and exclusions apply. Damage from abuse, impact, cutting, improper installation, or conditions outside the warranty terms may not be covered. Operators should request the current warranty document before ordering.
Washers Solutions also stocks Riser-related parts and supports operators with practical product guidance. As an operator-led car wash partner, the team understands uptime, service response, replacement components, and the cost of a door being down.
Downloadable Resources
This page should serve as the technical hub for Riser downloads. Final downloadable files should include the Riser specification sheet, installation manual, controller setup guide, anti-freeze mode instructions, warranty document, troubleshooting guide, and product videos when available.
If a download is not yet posted, use the car wash equipment resources hub or request the file through the contact form.
Riser Specification FAQs
What are the standard Riser door sizes?
The standard stocked Riser sizes are 10′ x 10′ and 12′ x 10′. Custom sizes are available as special order with an expected 12-week lead time.
What motor and controller specs are used?
The Riser uses a 220V single-phase motor and a wall or ground-level controller for speed, height settings, sensor settings, cycle count visibility, anti-freeze timing, and other door parameters.
Are heated rails available?
Heated rails should be treated as an available or launch-ready option, but final availability should be confirmed before publishing live inventory claims or placing an order.
Are transparent door sections available?
Yes. Transparent or full-vision sections are available as an option. They are not treated as the standard configuration and may affect price and lead time.
What is the current warranty?
The Riser currently has a one-year warranty with exclusions. Request the latest warranty document before ordering so coverage and exclusions are clear.
Does the door support Wi-Fi or remote access?
Yes. The Riser supports Wi-Fi and remote access functionality. Exact controller model, app, camera, network, and setup requirements should be confirmed during quoting.
Confirm Specs Before You Order
The Riser is built for operators who want a practical vinyl roll-up door with stocked standard sizes, controller-based setup, anti-freeze mode, stainless construction, and available replacement components. Before ordering, confirm opening size, color, transparent section needs, controller options, heated rail availability, and installation requirements.
Ready to compare specs or plan your door replacement? Request a Riser specification review and Washers Solutions will help match the door configuration to your bay.
